1956 Chevy Passenger Car Wiring Diagram
Stock may vary. Please call Mon-Fri 8am-5pm EST for current availability - 855-567-1957
Wiring diagrams are in the assembly manuals, but if you just need a wiring diagram, has you covered. The wiring diagram covers the complete chassis, overdrive, power windows and seats, air conditioning. directional signals, backup lights and neutral safety switch. You also get bulb specifications and the complete light switch circuit. 15571 covers the 1956 classic Chevy passenger cars only but information for the underdash and underhood wiring would be the same for Nomad and wagon.
NOTE: Stock may vary. Please call for current inventory.
Phone lines are open Mon-Fri 8am-5pm EST
Woody's sells the best products on the market for your Tri-Five. Part numbers listed in our system and catalog are for reference purposes only and make no reference towards manufacturer unless explicitly stated.
